| Performance | XG 430 Rev. 2 |
| Firewall throughput | 41 Gbps |
| Firewall IMIX | 14,5 Gbps |
| VPN throughput | 4,8 Gbps |
| IPS throughput | 9 Gbps |
| NGFW (IPS + App Ctrl) max. | 6 Gbps |
| Antivirus throughput (proxy) | 6,5 Gbps |
| Concurrent connections | 20,000,000 |
| New connections/sec | 200,000 |
| Maximum licensed users | unrestricted |
| Physical interfaces | |
| Storage (local quarantine/logs) | integrated SSD |
| Ethernet interfaces (fixed) |
8 GbE copper (incl. 2 bypass pairs)
2 10 GbE SFP+*
|
| No. of FleXi Port slots | 2 |
| FleXi Port modules (optional) |
8 port GbE copper
8 port GbE SFP*
2 port 10 GbE SFP+*
4 port 10 GbE SFP+*
2 port 40 GbE QSFP+*
4 port GbE PoE
8 port GbE PoE
4 port GbE copper LAN bypass
|
| Connectivity modules (optional) |
SFP DSL module (VDSL2)
SFP/SFP+ Transceivers
|
| I/O ports (rear) |
2 x USB 3.0 (front)
1 x Micro USB (front)
1 x USB 3.0 (rear)
1 x COM (RJ45) (front)
1 x IPMI (front)
1 x HDMI (rear)
|
| Display |
Multi-function LCD module
|
| Power supply |
Internal autoranging
100- 240VAC, 50-60 Hz
Redundant PSU optional (external)
|
| Physical specifications | |
| Mounting | 1U rackmount (sliding rails incl.) |
| Dimensions (Width x Depth x Height) |
438 x 507.7 x 44 mm
17.24 x 19.99 x 1.75 inches
|
| Weight |
7.6 kg / 16.76 lbs (unpacked)
13.7 kg / 30.2 lbs (packed)
|
| Environment | |
| Power consumption | 28W, 96 BTU/hr (idle) 79W, 270 BTU/hr (full load) |
| Operating temperature |
0-40°C (operating)
-20 to +80°C (storage)
|
| Humidity | 10%-90%, non-condensing |
| Product Certifications | |
| Certifications | CB, UL, CE, FCC, ISED, VCCI, MIC (Japan), RCM, CCC, KC Planned: BIS |
